1

Conductor

conductor cable consisting of pre-leads

2

Core Insulation

Mechanically high-quality TPE mixture.

3

Overall Shield

Bending-resistant braiding made of tinned copper wires. Coverage approx. 55% linear ,approx. 80% Optical.

4

Outer jacket

 Low adhesion mixture on the basis of PUR ,adapted to suit the requirements in energy chains•

Colour: pastel orange (Similar to RAL 2003).

5

Bending radius

Moved minimum 10 x d   Fixed minimum   5 x d

6

Temperature

Moved -20°C to +80°C

Fixed    -40°C to +80°C

7

V max.

 10m/s, 2m/s

8

Unsupported/ gliding a max

 50m/s2

9

Travel Distance

 Freely suspended travel distances and up to 10m for gliding applications, class 2

10

UV Resistant

Medium

11

Nominal Voltage

600/1000V (Following DIN  VDE 0250)

12

Testing Voltage

4000 V (Following DIN VDE 0281-2)

13

Oil

Oil-resistant ( Following DIN EN 50363-4-1) Class-2

14

Clean Room

According to ISO Class-2 outer jacket material complies with CFS.10.07 Tested by IPA According to stranded 14644-1

Typical application area:-

- For medium load requirements

- Almost unlimited resistance to oil

- Indoor and outdoor applications without direct sun radiation

- Freely suspended travel distances and up to 10m for gliding applications

- Machining units/ machine tools, low temperature applications
